Description
Complete heat-pump system—indoor and outdoor units included. Installation quoted separately.
Comfort without the direct cold draft
The Samsung WindFree™ AR24 first brings the room to temperature, then disperses air gently through thousands of micro air holes. As a result, you get steady heating and cooling without a strong stream of air blowing directly across the room.
Why choose Samsung WindFree™
- WindFree™ Cooling: maintains comfort with still-air dispersion after the room reaches the target temperature.
- Fast heating and cooling: Digital Inverter Boost helps bring rooms to temperature quickly.
- Smart control: built-in Wi-Fi works with Samsung SmartThings; you need a Wi-Fi connection and Samsung account.
- Automatic care: Samsung lists Tri-Care Filter, Easy Filter Plus, Freeze Wash and Auto Clean in its specification.
- Everyday modes: AI Auto Cooling, Fast Cool, Good Sleep and dehumidification.
AR24 specifications
| Indoor unit model | AR24BXECNWKNSA |
|---|---|
| Outdoor unit model | AR24BXECNWKXSA |
| Samsung room-size guide | Approximately 48–65 m² |
| Nominal cooling / heating | 6.8 kW / 7.2 kW |
| Operating capacity - cooling | 1.4-7.6 kW |
| Operating capacity - heating | 1.2-9.4 kW |
| EER / COP | 3.30 / 3.27 |
| Indoor unit dimensions | 1055 x 299 x 215 mm (W x H x D) |
| Outdoor unit dimensions | 880 x 638 x 310 mm (W x H x D) |
| Indoor sound pressure - high / low | 45 / 26 dB(A) |
| Maximum piping length / height | 30 m / 15 m |
| Refrigerant | R32 |
However, Samsung's room-size figures are a guide only. For example, orientation, glazing, insulation, ceiling height, occupancy and local heat loads affect correct sizing. Therefore, Airmax will confirm the appropriate system for your space before installation.
Warranty
Manufacturer warranty eligibility, registration requirements and current terms apply. Confirm the applicable warranty information before purchase or installation.
Frequently asked questions
Is the displayed price an installed price?
The displayed price includes both the indoor and outdoor units as a complete heat-pump system. Airmax quotes installation separately because pipe runs, electrical work, access and site conditions vary.
Can I control it from my phone?
Yes. Built-in Wi-Fi connects to Samsung SmartThings on compatible Android and iOS devices. You also need a Wi-Fi connection and Samsung account.
How do I know which capacity to choose?
Start with Samsung's room-size guide, then let Airmax assess the room, insulation, glazing and layout before you commit.
Before ordering, read our delivery, returns and refunds policy and terms and conditions. For property-specific sizing and installation, see our heat pump installation guide.
